Casagrand Athens

Specifications – Elite

Structure:

• Structural system: RCC framed structure designed for seismic compliant (Zone 3)
• Masonry: 200 mm for external walls and 100 mm for internal walls.
• Floor- Floor height (incl. slab): Shall be maintained at 2.95 mm
• ATT: Anti-termite treatment will be done

Wall Finish:

• Internal walls: Living, Dining, Bedrooms, Kitchen, Utility and Lobby finished with 2 coats of putty, 1 coat of primer and 2 coats of Emulsion paint
• Ceiling: Finished with 2 coats of putty, 1 coat of primer and 2 coats of OBD
• Exterior walls: Exterior faces of the building finished with 1 coat of primer and 2 coats of emulsion paint with color as per the architect’s design
• Bathroom: Glazed ceramic tile up to false ceiling height of size 300 x 600 mm and above false ceiling will be finished with a coat of primer
• Kitchen: Glazed / Matte Ceramic wall tile of size 600 x 600 mm for a height of 600 mm above the counter top finished level
• Toilet ceiling: Grid type false ceiling

Floor Finish:

• Foyer, Living, Dining, Bedrooms and Kitchen: Vitrified tiles of size 800 x 800 mm
• Bathroom: Anti-skid ceramic tiles of size 300 x 300 mm
• Balcony: Anti-skid ceramic tiles of size 300 x 300 mm
• Private open terrace (If applicable): Floor with pressed tiles

Kitchen and dining:

• Kitchen: Platform will be finished with granite slab 600 mm wide at a height of 800 mm from the finished floor level
• Electrical point: For chimney and water purifier
• CP Fitting: Jaquar / Roca or equivalent
• Sink: Single bowl matte finished stainless steel sink (or) carysil (Quartz) sink with drain board (OR) equivalent with pull out sink faucet.
• Drain: Pest free Square designer SS grating.
• Dining: Counter mounted wash basin wherever applicable.

Bathrooms:

• Sanitary Fixture: Jaguar/Roca OR equivalent
• CP fittings: Jaguar/Roca OR equivalent
• Bed 1-Bathroom: bathroom: Floor mounted WC with cistern; Health faucet; single lever concealed diverter with Rain Shower and arm, Counter top wash basin with granite or quartz platform, glass shower partition (fixed).
• Other Bathrooms: Floor mounted WC with cistern; Health faucet; single lever concealed diverter with overhead shower and arm, Wall mounted wash basin
• Drain: Pest free Square designer SS grating (all toilets) and long trench grating in bathing area Bed-1 bathroom.

Joinery:

• Main door:
  • Wide and fancy door of size 3’6” X 7’0” of good quality African teak wood frame with veneer finish shutter extended with an additional panel on one side.
  • Ironmongery like door lock of Digital lock system of Yale/Dorma OR equivalent, tower bolts, door viewer, safety latch, magnetic catcher.
• Bedroom doors:
  • Good quality door frame with skin shutters of double panel for a height (7’0” ht.) 2100mm
  • Ironmongery like door lock of Godrej OR equivalent locks, thumb turn with key, door stopper, door bush, tower bolt etc.
• Bathroom doors:
  • Good quality door frame with FRP molded shutters of height (7’0” ht.) 2100mm with water proofing resistant on inner side.
  • Ironmongery like thumb turns lock of Godrej OR equivalent and a latch.

Windows:

• Windows: UPVC windows with see through plain glass.
• French doors: UPVC frame and doors with toughened glass without grills.
• Ventilators: UPVC frame of fixed OR adjustable louvered OR open able shutter for ODU access

Electrical Points:

• Power Supply: 3 PHASE power supply connection.
• Safety device: MCB; ELCB (Earth leakage Circuit breaker)
• Switches and sockets: Modular box and modular switches and sockets of Anchor Roma / Schneider / equivalent
• Wires: Fire Retardant Low Smoke (FRLS) copper wire of a quality IS brand Finolex / Polycab / Anchor Roma or equivalent
• TV/ Telephone: Point in Living and Bedroom-1
• Data: Point in Living room
• Split- air conditioner: Point will be provided in Bedroom-1 and provision will be provided in Living and other bedrooms.
• Exhaust fan: Point will be given in all bathrooms
• Geyser: Geyser point will be provided in  Bed-1 bathroom  and provision will be provided in other bathrooms.
• Back-up: 500 W for 3 BHK, 400W for 2BHK and 350W             FOR 1 BHK.
• VDP: Video door phone will be provided in the entrance – Main door.
• Charging Pod: Mobile charging pod in Living room and Bedroom-1.
• Occupancy Sensor: Occupancy sensor will be provided in Foyer (if any) and all toilets.
• Bluetooth Speaker: Blue tooth speaker will be provided in the kitchen

Specifications – Signature:

Structure:

• Structural System: RCC Framed Structure designed for seismic compliant (Zone 3)
• Masonry: 200mm for external walls and 100mm for internal walls
• Floor- Floor height (incl. slab): Shall be maintained at 2.95m
• ATT: Anti–termite treatment will be done

Wall Finish:

• Internal walls: Living, Dining, bedrooms, Kitchen and lobby finished with 2 coat of putty and 1 coat of primer and 2 coats of Emulsion.
• Ceiling: Finished with 2 coat of putty 1 coat of primer and 2 coats of OBD.
• Exterior walls: Exterior faces of the building finished with 1 coat of primer and 2 coats of Emulsion paint with color as per architect design.
• Bathroom 1 and 2: Glazed/matte ceramic Tile of 400mm x 800mm will be finished up to false ceiling height and above false ceiling will be finished with a coat of primer.
• Bathroom 3 and 4: Glazed/matte ceramic Tile of 300mm x 600mm will be finished up to false ceiling height and above false ceiling will be finished with a coat of primer.
• Kitchen: Glazed/Matte Ceramic wall tile of size 600x 1200 mm for a height of 600mm above 800mm from finished floor level.
• Toilet ceiling: Grid type false ceiling

Floor Finish:

• Foyer, Living, Dining: Vitrified tiles of size 600x1200mm
• Bedrooms and Kitchen: Vitrified tiles of size 600x1200mm
• Bathroom 1 and 2: Anti-skid ceramic tiles of size 400x400mm
• Bathroom 3 and 4: Anti –skid ceramic tiles of size 300×300 mm
• Balcony: Anti-skid ceramic tiles of size 300x300mm.
• Private open terrace (if applicable): Floors with pressed tiles finish.

Kitchen and Dining:

• Kitchen: Platform will be finished with granite slab 600 mm wide at a height of 800 mm from the finished floor level
• Electrical point: For chimney and water purifier
• CP Fitting: Pull out top of American Standard / Kohler or equivalent
• Sink: Quartz Single bowl with drain board

Bathrooms:

• Sanitary Fixture: American Standard / Kohler or equivalent
• CP fittings: American Standard / Kohler or equivalent
• Bed 1-Bathroom: Floor mounted WC with cistern, Health faucet, Single lever diverter, Counter top wash basin and rain shower, glass partition with door, granite Anti-skid flooring and trench drain for shower area
• Other Bathrooms: Floor mounted WC with cistern, Health faucet, Single lever diverter, Counter top wash basin with granite counter, glass partition for shower area and SS trap
• Dining: Counter top wash basin with granite counter

Joinery:

• Main door:
  • Wide and fancy door of size 3’6” X 7’0” of good quality African teak wood frame with veneer finish shutter extended with an additional panel on one side.
  • Ironmongery like door lock of Digital lock system of Hafele/YALE OR equivalent, tower bolts, door viewer, safety latch, Magnetic catcher, door closure in SS finish.
• Bedroom doors:
  • Good quality door frame with laminated shutter of height (7’0” ht.) 2100mm
  • Ironmongery like door lock of Godrej OR equivalent locks, thumb turn with key, door stopper, door bush, tower bolt etc.
• Bathroom doors:
  • Good quality door frame with design moulded skin door with water proofing on inner side of height (7’0” ht.) 2100mm.
  • Ironmongery like thumb turn lock of Godrej OR equivalent and a latch.

Windows:

• Windows: UPVC windows with see through plain glass without grills.
• French doors: UPVC frame and doors with toughened glass without grills.
• Ventilators: UPVC frame of fixed OR adjustable louvered OR open able shutter for ODU access.

Electrical Points:

• Power Supply: 3 PHASE power supply connection.
• Safety device: MCB; ELCB (Earth leakage Circuit breaker)
• Switches and sockets: Modular box and modular switches and sockets of Anchor Roma / Schneider / equivalent
• Wires: Fire Retardant Low Smoke (FRLS) copper wire of a quality IS brand Finolex / Polycab /Anchor Roma/ equivalent.
• TV/ Telephone: Point in Living and Bedroom 1
• Data: Point in Living room
• Split- air conditioner: Point will be provided in Living and Bedroom-1 and provision will be provided in other bedrooms.
• Exhaust fan: Point will be given in all bathrooms
• Geyser: Geyser point will be provided in Bed-1 Bathroom and provision will be provided in other bathrooms.
• Back-up: 650W for 4BHK, 500 W for 3 BHK
• VDP: Video door phone will be provided in the entrance – Main door.
• Charging Pod: Mobile charging pod in Bed- 1 and living area
• Occupancy Sensor: Occupancy sensor will be provided in Foyer and toilets.
• Bluetooth Speaker: Blue tooth speaker will be provided in the kitchen and Bed- 1 bathroom.
